Stop Guessing Where the Leak Is — Call Masters Plumbing Service in Lerna, IL
The difference between a $300 pipe repair and a $3,000 drywall-and-remediation project is often just whether the leak was found before or after excessive wall opening. Our Leak Detection service in Lerna uses the same detection methods utilities and insurance adjusters rely on — to pinpoint the failure location before anything is cut.
4 Detection Capabilities We Bring to Every Leak Detection Call
A pressure test tells us a leak exists and how much water is escaping. Detection equipment tells us precisely where.
🎙️
Acoustic Ground Microphone
Pressurized supply line leaks create a distinctive low-frequency sound as water escapes the pipe and contacts surrounding soil or structure. Our acoustic listening devices amplify this signal, filtered for background noise, so we can walk a grid pattern and triangulate the loudest point — often to within 6–12 inches of the actual break.
🌡️
Infrared Thermal Camera
Thermal imaging is particularly effective inside insulated wall cavities and for finding the extent of moisture spread beyond the immediate leak point. It tells us not just where the pipe is failing but how far the moisture has already traveled.
📉
Pressure Decay Testing
Pressure decay testing is the standard by which we confirm a leak is present before committing detection equipment time. It also tells us approximately how significant the leak is — a rapid pressure drop vs. a slow one indicates the size of the escape point.
💨
Tracer Gas Detection
For leaks that don't produce sufficient acoustic signature — very slow leaks, polyethylene pipe, or leaks deep under concrete — we can introduce a nitrogen/hydrogen tracer gas mixture into the isolated pipe and use a calibrated gas detector at the surface to find where the gas escapes. The detection sensitivity can locate leaks that produce no discernible pressure drop during a standard timed test.
What We Locate
Every Leak Detection Scenario We Handle in Lerna, IL
Hidden leaks occur in different locations throughout a property — each requiring a slightly different detection approach. Here's how we handle the most common scenarios in Lerna, IL.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
We document the thermal anomaly, mark the approximate pipe location, and recommend a minimal access cut rather than a wide wall opening.
Water Main
Underground Supply Line Detection
We mark the ground above the detected leak location so the repair crew opens only the section they need to.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Irrigation system leaks in main supply lines and lateral runs are found by isolating zones with the irrigation controller and pressure-testing each zone individually. Zone by zone testing narrows the failure to the smallest possible section.
Commercial
Commercial Property Leak Detection
Multi-story buildings, commercial kitchens, retail spaces, and industrial properties have complex pipe networks where a supply or drain leak can go undetected through multiple floors before surfacing. We approach commercial detection systematically — zone by zone pressure isolation, thermal scan of suspect surfaces, and acoustic confirmation.
Documentation
Leak Detection Report for Insurance
We format detection reports specifically for insurance submission and can provide documentation on our detection equipment and methodology to claims adjusters on request.
Finding a hidden leak isn't a single step — it's a protocol that combines water loss confirmation, zone isolation, and targeted detection in sequence.
1
Initial Water Loss Confirmation
We start at the meter. All fixtures off, we watch the meter for 10 minutes. Movement confirms active water loss from the supply side. We also check for any visible evidence — water stains, soft floors, moisture readings with a moisture meter at suspect wall surfaces.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
We document findings with thermal images and note detection readings at multiple grid points to triangulate the strongest signal.
4
Written Report & Repair Options
Insurance claims: the report is formatted to support a claim for water damage from a concealed leak. We can provide supplemental documentation on request.
Customer Reviews
What Customers Say About Our Detection Service
★★★★★
High-efficiency home with a leak that defied normal detection. Water loss was slow — about 1.5 gallons per hour. The tech used tracer gas after pressure testing confirmed the loss but acoustic detection couldn't localize it clearly. Gas detection found the escape at a micro-fitting under the slab in the utility corridor. Impressive work.
— C. Thornton, Lerna
★★★★★
Our insurance company required professional leak detection documentation before approving the claim. Masters Plumbing Service's written report with pressure test data and thermal imagery was exactly what the adjuster needed. Claim approved. The detection cost was covered as part of the claim.
— B. Osei, Lerna, IL
★★★★★
Pool was losing 2 inches of water per day — more than evaporation could explain. Masters Plumbing Service pressure-tested the plumbing circuit, isolated the issue to the return line, and ran acoustic detection along the line path to find the failure at a union fitting under the decking. Repair required pulling one deck board instead of the exploratory digging another company had proposed. Excellent, focused work.
— T. Anand, Lerna, IL
Common Questions
Leak Detection Questions We Answer in Lerna
Secondary indicators: water stains appearing or recurring in the same area without an obvious source; mold or mildew smell in rooms without a plumbing fixture; soft or discolored flooring; consistent sound of running water in walls when all fixtures are off.
The repair itself requires physical pipe access, which typically means a small, targeted opening. But that's a completely different proposition from opening large wall sections while searching for an unknown leak location.
For pressurized supply lines in concrete or metal pipe, acoustic detection is typically accurate to within 6–18 inches under ideal conditions — quiet environment, no interference from other water use, metal pipe conducting sound clearly. Thermal imaging is accurate to the size of the wet zone it reveals, which varies based on how long the leak has been running and how far moisture has migrated.
We can provide supplemental information to claims adjusters on request, including equipment calibration records and a technical description of the detection methodology used.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
The repair quote is given before any wall or floor is opened. You know the full cost of detection + repair before anything is cut.
Service Area
Serving Lerna and the Surrounding Lerna, IL Region
Our detection technicians are equipped with acoustic, thermal, and tracer gas tools for the full range of leak scenarios found in Lerna, IL homes and commercial properties.
Don't Open Walls Blind — Call +1-855-718-1500 First
Masters Plumbing Service's detection team finds hidden leaks in Lerna homes and commercial properties using equipment that eliminates guesswork. The detection appointment pays for itself the moment it prevents one unnecessary wall opening.
